2011–2016 Duramax LML Shift on the Fly Switch

Easily switch between compatible custom tune files with this Shift on the Fly (SOTF) Switch for 2011–2016 LML Duramax trucks.

This switch allows you to select between multiple custom calibrations without stopping to reflash your ECM. Whether you're towing, commuting, or looking for maximum performance, you can select the tune that best fits your driving conditions with the turn of a knob.

Designed specifically for compatible 2011–2016 LML Duramax tuning applications, this switch provides a clean, convenient way to control multiple selectable tune levels.

Features

• Designed for compatible 2011–2016 LML Duramax tuning
• Switch between multiple custom tune positions
• High-quality rotary selector
• Clean, factory-style installation
• Reliable and durable construction
• Convenient access to different power levels

Compatible custom tuning is required. This switch does not include tuning files.

Installation Instructions

2011–2016 LML Shift on the Fly Switch

1. Disconnect both negative battery cables.
2. Locate the Engine Control Module (ECM).
3. Identify the appropriate ECM connector and terminal locations for your specific LML switch and tuning configuration.
4. Disconnect the appropriate ECM connector.
5. Remove the connector lock and carefully access the rear of the connector.
6. Install the supplied switch terminals into the specified ECM terminal locations.
7. Verify that both terminals are completely seated and locked into the connector.
8. Reassemble the connector and reconnect it to the ECM.
9. Route the switch wiring through the firewall, keeping it away from moving parts, sharp edges, and excessive heat.
10. Mount the switch in your desired dash location.
11. Reconnect both negative battery cables.

Important: Verify the correct ECM connector, pin locations, and wire orientation for your specific LML switch before inserting any terminals.

Verify Installation

1. Turn the ignition to the ON position without starting the engine.
2. Verify switch operation according to the instructions supplied with your compatible tuning.
3. Rotate the switch through each position and confirm that the selected tune position is recognized.
4. If the switch does not operate correctly, turn the ignition off and verify the ECM terminal locations and that both terminals are completely seated.

Important Information

• Compatible custom tuning is required for the switch to function.
• No tune files are included.
• The switch alone does not add horsepower or modify the vehicle calibration.
• Installation requirements may vary depending on the tuning system and switch configuration.
• Professional installation is recommended if you are unfamiliar with ECM connectors or automotive electrical wiring.

Complete your custom tuning package by adding a 2011–2016 LML Shift on the Fly Switch and enjoy the convenience of selecting between multiple custom calibrations without having to reflash the ECM each time.
